Online Low-range Turbidity Analyzer with LCD Display for Water Plants
Application Fields
This product is widely applied to the online turbidity monitoring of water before filtration, after filtration, and finished water in water treatment plants, as well as in direct - drinking water systems. It is also commonly used for the online turbidity monitoring in various industrial production circulating cooling water, filtered effluent, and reclaimed water reuse systems.
Functional features
Dual - channel access, configurable according to requirements.
Achieves plug - and - play for sensors, enabling rapid and convenient electrode installation and replacement.
The operation interface is simple, reducing the possibility of operational errors and ensuring reliable results.
Features visual operation on the LCD screen, with a rich and comprehensive interface.
Equipped with multiple data output methods such as 4 - 20mA and MODBUS RS485.
The transmitter supports wall - mounted installation / panel - mounted installation / pipe - clip installation.
Crafted from aluminum alloy, it offers high strength, oxidation resistance, and corrosion resistance, enhancing its texture and market attractiveness.
Technical Parameters
Specification | Detailed information | |
Measurement | Measurement Parameters | Low range turbidity |
Measuring Ranges | 0.01-100 NTU | |
Resolution | 0.1～0.1NTU（depending on the measuring range） | |
Accuracy | When the turbidity value is in the range of 0.001 - 40 NTU, the tolerance is ±2% of the reading or ±0.015 NTU, take the greater one. When the turbidity value is in the range of 40 - 100 NTU, the tolerance is ±5% of the reading. | |
Repeatability | ±2% | |
Resolution | 0.001 - 0.1 NTU, depending on different measurement ranges. | |
Water Sample Flow Rate | 300 mL/min ≤ X ≤ 700 mL/min | |
Pipe Fittings | Sampling inlet: 1/4 NPT Discharge outlet: 1/2 NPT | |
Main material of the sensor | Body: ABS + SUS316L Sealing parts: Nitrile rubber Cable: PUR | |
Storage temperture | -15°C to 60°C | |
Operating Temperature | 0°C to 45°C (without freezing) | |
Weight | 2.1KG | |
Protection level | IP65 (for indoor use) | |
Cable length | The standard length is 3m. For the LED version, it can be extended up to 30 meters at most. | |
Power consumption | The LED - version sensor has a low power consumption of 3.5W. | |
Electrical | Display | LCD liquid - crystal screen |
Power supply | 105～235VAC，50±1Hz/24VDC±5%(DC is optional) | |
Power | ≤12W（including the sensor） | |
Analog Output | Two ways of analog outputs (load resistance < 500Ω) | |
Digital output | RS485 interface, MODBUS RTU protocol | |
Relay output | Three-way relay 5A 250VAC，5A 30VDC | |
Physical prosperities | Material | Bottom shell: Cast aluminum with plastic spray coating Top cover: PA66 + 30GF with paint coating |
Size | 145*145*174mm（H*W*D） | |
Weight | 1.8kg（Not including the sensor） | |
Waterway interface | 2-inch or 3-inch hose （custom made） | |
Ambient performance | Flow rate | In flow chamber：250～500mL/min |
Protection level | IP65 | |
Water pressure | ≤6 bar（matching a pressure - reducing valve with the instrument） | |
Working humidity | <90%，no condensation | |
Working temperature | Instrument：-15℃～50℃；senseor water temperature：0.1℃～45℃（0.1°C to 70°C for special applications） | |
Storage temperature | Instrument：-20°C～60°C；sensor：0.1°C～55°C | |
